商品の詳細:
|
| 鋼種: | 合金鋼 | 合金かどうか: | 合金です |
|---|---|---|---|
| 技術: | コールドドロー | 応用: | 構造鋼棒 |
| タイプ: | 合金鋼棒 | 標準: | ASTM、DIN、AISI、JIS |
| 形: | 丸い、正方形 | 長さ: | 1m～6m |
| 製品名: | 42crmo4 qt 合金鋼丸棒 | 表面処理: | //ポーランド語黒い/機械で造られる皮をむくこと |
| 直径: | 12mmから650mm | 配信条件: | アニール |
| 寸法: | ダイア 8-60mm | 学年: | 42CrMo4 |
| 熱処理: | 正常化された+Annealedは+Quenched +和らげた |
| component | C | Si | Mn | P | S | Cr | Ni | Cu | Mo |
| minimum value | 0.38 | 0.17 | 0.5 | - | - | 0.9 | - | - | 0.15 |
| maximum value | 0.45 | 0.37 | 0.8 | 0.035 | 0.035 | 1.2 | 0.3 | 0.3 | 0.25 |
| ISC | CNS | JIS | KS | ASTM/AISI | UNS | ISO | DIN EN/DIN | W-Nr. | NF EN/NF | EN | Digital brandGB | SS14 | BS EN/BS | |
| 42CrMo | A30422 | SCM440 | SCM440 SCM440H |
SCM440 | 4140 | G41400 | 42CrMo4 | 42CrMo4 | 1.7225 | 42CD4 | 42CrMo4 | 1.7225 | 2244 | 708M40 |
|
Commodity
|
Cold Drawing / Drawn Flat/ Square / Rectangular / Rectangle / Hexagonal / Special Shape Rods Bars
|
|
|
Grades
|
Carbon steel
|
SAE 1018 , A36, SS400, S235JR, Q235, SAE 1020, S20C , 1.0402, 20GB, CK22,
SAE 1045 ,S45C, C45, CK45, EN8 ,1.1191 |
|
Alloy steel
|
SAE 5120 , 20Cr, Scr 420H, 20Cr4, SAE 5140 , 40Cr,SCr440, 520M40,
SAE 4130 , 30CrMo, SCM430, SCM420, SAE 4140 , 42CrMo4, EN19, SCM440, 708A42, 708M40, SAE 4340, 40CrNiMoA,871M40 , SNCM439 |
|
|
Specification
|
Round Bar
|
5mm to 100mm
|
|
Square bar
|
5*5mm to 120*120mm
|
|
|
Flat bar
|
5*20mm to 20*100mm
|
|
|
hex bar
|
5mm to 120mm
|
|
|
hexagonal bar
|
5mm to 120mm (side to side)
|
|
|
Length
|
4-12m random length or as per request fixed length
|
|
|
Surface
|
Bright, or dark as per required
|
|
|
Packing
|
Wrapped by plastic clothes and steel strips
|
|
|
Delivery Condition
|
BK, BKW, GBK, NBK
|
|
|
Container
Size |
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
|
|
Application
|
hardware tools, auto parts, standard parts, fasteners common shaft, machinery manufacturing, light industry, hardware, bicycles,
cars, motorcycles, textile machinery, transformers and other machinery industry. |
|
|
Advantages
|
greater size accuracy, straightness and increased tensile and yield strength as well as improved machinability
|
|
|
MOQ
|
1 tons
|
|
| Material | Diameter of sample d mm |
Heat treatment or condition. | Tensile strength σb Mpa |
Point of yield σs Mpa |
Ratio of elongation δ % |
Reduction of section ψ % |
hardness HBW |
Shock absorption energy KV2 J |
| ASTM 5115 45Cr |
d=15 | Quenching + tempering | ≥735 | ≥490 | ≥11 | ≥45 | ≤179 | ≥55 |
| ASTM 5120 20Cr |
d=15 | Quenching + tempering | ≥835 | ≥540 | ≥10 | ≥40 | ≤179 | ≥47 |
| ASTM 5130 30Cr |
d=25 | Quenching + tempering | ≥885 | ≥685 | ≥11 | ≥45 | ≤187 | ≥47 |
| ASTM 5135 35Cr |
d=25 | Quenching + tempering | ≥930 | ≥735 | ≥11 | ≥45 | ≤207 | ≥47 |
| ASTM 5140 40Cr |
d=25 | Quenching + tempering | ≥980 | ≥785 | ≥9 | ≥45 | ≤207 | ≥47 |
| ASTM 5145 45Cr |
d=25 | Quenching + tempering | ≥1030 | ≥835 | ≥9 | ≥40 | ≤217 | ≥39 |
| ASTM 4119 |
d=30 | Quenching + tempering | ≥410 | ≥265 | ≥24 | ≥60 | ≤179 | ≥110 |
| ASTM 4130 | d=25 | Quenching + tempering | ≥930 | ≥785 | ≥12 | ≥50 | ≤229 | ≥63 |
| ASTM 4317 | d=25 | Quenching + tempering | ≥980 | ≥835 | ≥12 | ≥45 | ≤229 | ≥63 |
| ASTM 4140 | d=25 | Quenching + tempering | ≥1080 | ≥930 | ≥12 | ≥45 | ≤217 | ≥63 |
| GB38CrMoAI/ JIS SCM645 |
d=30 | Quenching + tempering | ≥980 | ≥835 | ≥14 | ≥50 | ≤229 | ≥50 |
| ASTM 6150 | d=25 | Quenching + tempering | ≥1280 | ≥1130 | ≥10 | ≥40 | ≤255 | d=25 |
| ASTM 4142 | d=25 | Quenching + tempering | ≥980 | ≥785 | ≥10 | ≥45 | ≤217 | ≥63 |
