商品の詳細:
|
| 配送日: | 前払いを受け取ってから7〜15日 | ポート: | 上海、寧波 |
|---|---|---|---|
| 配送条件: | HR、CR、AR、Q+T、N+T、N、TMCP、UT、Z方向 | 起源: | 中国 |
| 輸送パッケージ: | 必要に応じて | 形: | 正方形 長方形 丸皿 |
| パッキング: | 標準梱包 | 主な用途: | 建物の橋の家の装飾 |
| 支払い期間: | 30%T/T アドバンス + 70% バランス | 合金かどうか: | 合金です |
| 材料: | A36 | 加工サービス: | 曲げ、溶接、デコイ、切断 |
MITTEL ------Professional manufacturer of carbon/galvanized/stainless steel/aluminum checkered steel sheet/plate etc.steel products for more than 10 years.And we can produce diamond,round bean,5bar etc.patterns,could you please tell us the size and quantity you need, we'd like to update the latest price according to your needs.
Application: It is widely used in the fields of transportation, construction, decoration, equipment, machinery, shipbuilding and other fields
| Grade | Carbon/Galvanized | Stainless | Aluminium |
Q235,SS400,St37-2,St52,ASTMA36, | 201,202,301,302,304,304L,310S, 310, 309, 309S, 316, 316L, 316Ti,403, 405, 409, 409L, 410, 410S, 420, 430....... | 1050,1060,1100,2024,2204,3003, 5052, 5754...... | |
| Thickness | 2-10mm(2-8mm usually used) | ||
| Width | 1000-2000mm (1250 and 1500mm usually used) | ||
| Length | 1000-12000mm or as your request | ||
| Surface | Carbon,Galvanized,Stainless,Aluminium | ||
| Pattern | Diamond,Round Bean,Hyacinth Bean,5 Bar...... | ||
| Carbon Checkered Plate Theoretical Weight(Kg/ m²) | ||||||||||
| Pattern/Thc(mm) | (Diamond) | (Tear Drop) | (Round Bean) | |||||||
| 2.5 | 21.6 | 21.3 | 21.1 | |||||||
| 3 | 25.6 | 24.4 | 24.3 | |||||||
| 3.5 | 29.5 | 28.4 | 28.3 | |||||||
| 4 | 33.4 | 32.4 | 32.3 | |||||||
| 4.5 | 37.3 | 36.4 | 36.2 | |||||||
| 5 | 42.3 | 40.5 | 40.2 | |||||||
| 5.5 | 46.2 | 44.3 | 44.1 | |||||||
| 6 | 50.1 | 48.4 | 48.1 | |||||||
| 7 | 59 | 52.6 | 52.4 | |||||||
| 8 | 66.8 | 56.4 | 56.2 | |||||||
| Stainless Checkered Plate Theoretical Weight(Kg/ m²) | ||||||||||
| Thickness(mm) | (Kg/ m²) | |||||||||
| 2.5 | 22.6 | |||||||||
| 3 | 26.6 | |||||||||
| 3.5 | 30.5 | |||||||||
| 4 | 34.4 | |||||||||
| 4.5 | 38.3 | |||||||||
| 5 | 42.3 | |||||||||
| 6 | 50.1 | |||||||||
| 8 | 66.8 | |||||||||
Aluminium Checkered Plate Theoretical Weight(Kg/ m²) | ||||||||||
| Material Thc(mm) | LY12 (2024) | LY11 (2.8) | L1-L6() Pure Aluminium | LY11 (2017) | LF6 KF43 | LY11 | ||||
| 1 | 3.45 | - | - | - | - | - | ||||
| 1.2 | 4.01 | - | - | - | - | - | ||||
| 1.5 | 4.84 | - | 4.67 | - | 4.62 | - | ||||
| 1.8 | 5.68 | - | - | - | - | - | ||||
| - | - | - | - | - | - | - | ||||
| 2 | 6.23 | 6.9 | 6.02 | 5.06 | 5.96 | - | ||||
| 2.5 | 7.62 | 8.3 | 7.38 | 7.46 | 7.3 | - | ||||
| 3 | 9.01 | 9.7 | 8.73 | 8.86 | 8.64 | 9.1 | ||||
| 3.5 | - | 11.1 | 10.09 | 10.26 | 9.98 | - | ||||
| 4 | - | 12.5 | 11.44 | 11.66 | 11.32 | 11.95 | ||||
| 4.5 | - | - | 12.8 | - | - | - | ||||
| 5 | - | - | - | - | - | 15.35 | ||||
Due to its high strength, good toughness, easy processing and good weldability and other excellent properties, steel plates are widely used in ships, automobiles, bridges, construction, machinery, pressure vessels and other manufacturing industries.
| Product Name: | ASTM A36 Low carbon Mild Steel Chequered Plate Checkered Steel Plate Steel Checker Plate Ms Chequered Plate Carbon Steel Sheet |
| Material: | 0.2-150mm,etc |
| Thickness: | 2000mm, 2500mm, 3000mm, 3500,6000mm,8000mm,or rolled,etc |
| Length: | ASTM,AISI,JIS,GB, DIN,EN |
| Standard: | Black painted,PE coated,Galvanized,color coated, |
| Surface: | anti rust varnished,anti rust oiled,checkered,etc |
| Technique: | Cold Rolled, Hot Rolled |
| Certification: | ISO, SGS,BV |
| Delivery Detail: | 7-15day |
| Export to | Singapore,Indonesia,Ukraine,Korea,Thailand,Viet Nam,Saudi Arabia,Brazil,Spain,Canada, USA,Egypt,India,Kuwait,Dubai,Oman,Kuwait,Peru,Mexico,Iraq,Russia,Malaysia,etc |
| Payment Terms: | T/T, L/C at sight,West Union,,Paypal |
Chequer plates offer an easy access for vehicles and combine a closed surface with an anti slip effect. They are ideally suitted for platforms or as a design element.
Carbon steel embossed plate is a steel plate with embossed surface, which belongs to steel plate. There are different materials such as Q195, Q215, Q235, SS400, etc. The appearance of carbon steel checkered plate is beautiful and anti-skid. It is widely used in transportation, architecture, decoration, equipment surrounding floor, machinery, shipbuilding and other fields.
A: We are professional manufacturer for steel pipe/sheet/coil, and our company also is a very professional a trade
company for steel products.we can also provide a wide range of steel products.
Q: Will you delivery the goods on time?
A: Yes,we promise to provide best quality products and delivery on time .Honesty is our company's tenet.
Q: Do you provide samples ? is it free or extra ?
A: The sample could can provide for customer with free,but the courier freight will be covered by customer account.
Q: What is the terms of trade?
A: EXW, FOB, CIF, CFR, DDU.
Q: What is the terms of packing?
A: Generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers'
requirement.
Q: What is your delivery time?
A: For stocks, we could transport the goods to loading port within 7 days after received your deposit. For productiong
period, it usually takes about 15-30 days afer receiving the deposit.
Q: Could you produce according to the samples?
A: Yes, we could customer-made by your samples or technique drawings, we could build the mold and fixtures.
