商品の詳細:
|
| 幅: | 600-2500mm | 学年: | Q235B A36 |
|---|---|---|---|
| 技術: | ホットロール | タイプ: | 鋼板 |
| 標準: | ASTM、AISI、JIS、DIN | 長さ: | 1000〜12000mm |
| 厚さ: | 1mm-120mm | 形: | 平らな鋼板 |
| ハイライト: | Q235B carbon steel plate,S235JR steel plate with warranty,ASTM A36 carbon steel plate |
||
|
Brand
|
MITTEL |
|
Technology
|
Hot rolled/Cold rolles
|
|
Standard
|
ASTM,JIS,AISI,GB,DIN,TUV,BV,SUS.
|
|
Aluminium
|
Q235,Q345R,SA302,SA516,A572,S275,S355
|
|
Thickness
|
1-150mm
|
|
Width
|
300-1500mm
|
|
Length
|
customlzed
|
|
Shap
|
flat Plate
|
|
Application
|
Steel structures, bridges, ships and vehicles, machinery, metal doors, beds, automobiles and buildings, etc.
|
|
Processing service
|
Bending, welding, uncoiling, cutting and stamping.
|
|
Delivery time
|
Inventory for 10 days; 15-30 days according to the quantity.
|
|
Payment methods
|
Telegraphic transfer or letter of credit
|
|
Price term
|
CIF; CFR; FOB;EXW;L/C;T/T.
|
|
Port of delivery
|
China Qingdao Port, Tianjin Port and Shanghai Port.
|
|
Shipping Address
|
China
|
| Specifications | ASTM / ASME |
| Standard | EN 10025-2: 2004 Hot rolled products of structural steels. Technical delivery conditions for non-alloy structural steels |
| Specialize | Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Size | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| USA | Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
Canada HG |
European old EN |
Belgium NBN |
Spain UNE |
| 1015 A283C SSGr.33 |
RSt37-2 St37-2 |
SM400A SS400 |
E24-2 | 40A 40B |
230G | Fe360B Fe360BFN S235JRG2 |
AE235B | AE235B-FN |
| A283D A529 Gr.D |
RSt42-2 St 44-2 |
SS400 | E28-2 | 161-430 43A 43B |
260W 260WT |
Fe430B | AE295B | AE255B |
|
C
|
Mn
|
P
|
S
|
Si
|
Co
|
CEV
|
|
max 0.27
|
max 1.20
|
max 0.04
|
max 0.05
|
0.15 – 0.40
|
max 0.20
|
–
|
| Yield Point ksi, min | Tensile Strength ksi | % Elong. 2” Bend |
| 36 | 58-80 | 23 |
FAQ
1. How to buy your ideal products?
A: You can provide us your drawing, and we will produce as your drawing. Or we can design as your requirements if you do not have a clear plan.
2. How to pay?
A: TT and L/C are acceptable and TT will be more appreciated.
30% deposit before producing, 70% balance before loading by TT.
3. What is the delivery time?
A: It depends on order quantity.
Generally, the delivery time will be within 12 to 15 days.
4. How to install after the goods destination?
A: We will provide installation instruction and video for you. Technicians will be sent to help you if it is necessary. However, the visa fee, air tickets, accommodation, wages will be provided by buyers.
